Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Ezurio |
| Series | Nitrogen8M |
| Packaging | Tray |
| Part Status | Active |
| Core Processor | ARM® Cortex®-A53, Cortex®-M4 |
| Speed | 400MHz, 1.8GHz |
| Number of Cores | 1/4 |
| Power (Watts) | – |
| Cooling Type | – |
| Size / Dimension | 3.228″ x 1.969″ (81.99mm x 50.01mm) |
| Form Factor | SMARC2.1.1 |
| Expansion Site/Bus | Audio, CAN, GPIO, I2C, LVDS, MIPI CSI, MIPI DSI, PCIe, UART, Wi-Fi/Bluetooth |
| RAM Capacity/Installed | 4GB/0GB |
| Storage Interface | eMMC, SPI |
| Video Outputs | LVDS, MIPI CSI, MIPI DSI |
| Ethernet | GbE |
| USB | USB 2.0 (3) |
| Digital I/O Lines | – |
| Analog Input:Output | – |
| Watchdog Timer | No |
| Contents | – |
| Operating Temperature | -40°C ~ 85°C |
