Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | EPCOS – TDK Electronics |
| Series | B3202* – Y2 Standard |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Active |
| Capacitance | 4700 pF |
| Tolerance | ±10% |
| Voltage Rating – AC | 300V |
| Voltage Rating – DC | 1500V (1.5kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -40°C ~ 110°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.512″ L x 0.197″ W (13.00mm x 5.00mm) |
| Height – Seated (Max) | 0.433″ (11.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.394″ (10.00mm) |
| Applications | EMI, RFI Suppression |
| Ratings | Y2 |
| Features | – |
