Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | ECS Inc. |
| Series | ETXO-L ECSpressCON™ |
| Packaging | Tray |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | TCXO |
| Frequency | 100 MHz |
| Function | Enable/Disable |
| Output | LVDS |
| Voltage – Supply | 3.3V |
| Frequency Stability | ±2.5ppm |
| Absolute Pull Range (APR) | – |
| Operating Temperature | -30°C ~ 85°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 25mA |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, No Lead |
| Supplier Device Package | 6-SMD (3.2×2.5) |
| Size / Dimension | 0.126″ L x 0.098″ W (3.20mm x 2.50mm) |
| Height – Seated (Max) | 0.067″ (1.70mm) |
| Current – Supply (Disable) (Max) | 18mA (Typ) |
