Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | ECS Inc. |
| Series | ECS-VXO-73 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | VCXO |
| Frequency | 20 MHz |
| Function | Enable/Disable |
| Output | CMOS |
| Voltage – Supply | 3.3V |
| Frequency Stability | ±50ppm |
| Absolute Pull Range (APR) | – |
| Operating Temperature | -10°C ~ 70°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 20mA |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, No Lead |
| Supplier Device Package | 6-SMD (7×5) |
| Size / Dimension | 0.276″ L x 0.197″ W (7.00mm x 5.00mm) |
| Height – Seated (Max) | 0.063″ (1.60mm) |
| Current – Supply (Disable) (Max) | – |
