Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | ECS Inc. |
| Series | ECX-1247 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | MHz Crystal |
| Frequency | 38.4 MHz |
| Frequency Stability | ±10ppm |
| Frequency Tolerance | ±10ppm |
| Load Capacitance | 10pF |
| ESR (Equivalent Series Resistance) | 80 Ohms |
| Operating Mode | Fundamental |
| Operating Temperature | -20°C ~ 70°C |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Supplier Device Package | 4-SMD (1.6×1.2) |
| Size / Dimension | 0.063″ L x 0.047″ W (1.60mm x 1.20mm) |
| Height – Seated (Max) | 0.014″ (0.35mm) |
