Açıklama

ÖZELLİK	AÇIKLAMA
Mfr	ECS Inc.
Series	ECS-2532HS
Packaging	Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Part Status	Active
Base Resonator	Crystal
Type	XO (Standard)
Frequency	50 MHz
Function	Enable/Disable
Output	CMOS
Voltage – Supply	3.3V
Frequency Stability	±10ppm
Absolute Pull Range (APR)	–
Operating Temperature	-40°C ~ 85°C
Spread Spectrum Bandwidth	–
Current – Supply (Max)	10mA
Ratings	–
Mounting Type	Surface Mount
Package / Case	4-SMD, No Lead
Supplier Device Package	4-SMD (3.2×2.5)
Size / Dimension	0.126″ L x 0.098″ W (3.20mm x 2.50mm)
Height – Seated (Max)	0.043″ (1.10mm)
Current – Supply (Disable) (Max)	10µA
