Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | ECS Inc. |
| Series | ECOC-2522 |
| Packaging | Tray |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | OCXO |
| Frequency | 100 MHz |
| Function | – |
| Output | CMOS |
| Voltage – Supply | 3.3V |
| Frequency Stability | ±30ppb |
| Absolute Pull Range (APR) | – |
| Operating Temperature | -40°C ~ 75°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | – |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, No Lead, 5 Leads |
| Supplier Device Package | 5-SMD (25.4×22.1) |
| Size / Dimension | 1.000″ L x 0.870″ W (25.40mm x 22.10mm) |
| Height – Seated (Max) | 0.488″ (12.40mm) |
| Current – Supply (Disable) (Max) | – |
