Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Ecliptek |
| Series | EC36 |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | XO (Standard) |
| Frequency | 24 MHz |
| Function | Enable/Disable |
| Output | LVCMOS |
| Voltage – Supply | 3.3V |
| Frequency Stability | ±20ppm |
| Absolute Pull Range (APR) | – |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 10mA |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.197″ L x 0.126″ W (5.00mm x 3.20mm) |
| Height – Seated (Max) | 0.051″ (1.30mm) |
| Current – Supply (Disable) (Max) | 10µA |
