Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Crystek Corporation |
| Series | CCHD-957 |
| Packaging | Strip |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | XO (Standard) |
| Frequency | 45.1584 MHz |
| Function | Enable/Disable |
| Output | HCMOS |
| Voltage – Supply | 3.3V |
| Frequency Stability | ±25ppm |
| Absolute Pull Range (APR) | – |
| Operating Temperature | 0°C ~ 70°C |
| Current – Supply (Max) | 25mA |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.559″ L x 0.360″ W (14.20mm x 9.14mm) |
| Height – Seated (Max) | 0.209″ (5.30mm) |
| Current – Supply (Disable) (Max) | 1.5mA |
