Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Cornell Dubilier Knowles |
| Series | Orange Drop® 719P |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 3300 pF |
| Tolerance | ±5% |
| Voltage Rating – AC | 1500V (1.5kV) |
| Voltage Rating – DC | 5000V (5kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 139 mOhms |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.598″ L x 0.382″ W (40.60mm x 9.70mm) |
| Height – Seated (Max) | 0.579″ (14.70mm) |
| Termination | PC Pins |
| Lead Spacing | 1.406″ (35.70mm) |
| Applications | Audio; High Pulse, DV/DT |
| Ratings | – |
| Features | – |
