Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Cornell Dubilier Knowles |
| Series | TTA |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage – Rated | 35 V |
| ESR (Equivalent Series Resistance) | 90.4mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | – |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.81 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.3168 A @ 50 kHz |
| Lead Spacing | – |
| Size / Dimension | 0.630″ Dia x 1.614″ L (16.00mm x 41.00mm) |
| Height – Seated (Max) | – |
| Surface Mount Land Size | – |
| Mounting Type | Through Hole |
| Package / Case | Axial, Can |
