Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Amphenol Aerospace Operations |
| Series | Tri-Start™ CF |
| Packaging | Bag |
| Part Status | Active |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 1 |
| Grade | – |
| Qualification | MIL-DTL-38999 Series III |
| Shell Size – Insert | 11-1 |
| Shell Size, MIL | – |
| Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead – Front Side Nut |
| Termination | Crimp |
| Fastening Type | Threaded |
| Orientation | N (Normal) |
| Shell Material | Aluminum |
| Shell Finish | Electroless Nickel |
| Contact Finish – Mating | – |
| Color | Silver |
| Ingress Protection | – |
| Material Flammability Rating | – |
| Features | – |
| Shielding | Unshielded |
| Current Rating (Amps) | – |
| Voltage Rating | – |
| Cable Opening | – |
| Operating Temperature | -65°C ~ 200°C |
| Backshell Material, Plating | – |
| Contact Material | – |
| Contact Finish Thickness – Mating | – |
| Insert Material | – |
| Applications | Aerospace, Automotive, Commercial, Medical, Military, Test Equipment |
