Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Adam Tech |
| Series | EB |
| Packaging | Box |
| Part Status | Active |
| Number of Levels | 1 |
| Positions Per Level | 4 |
| Pitch | 0.197″ (5.00mm) |
| Mating Orientation | Horizontal with Board |
| Current | 8 A |
| Voltage | 300 V |
| Wire Gauge | 16-26 AWG |
| Mounting Type | Through Hole |
| Wire Termination | Screw – Rising Cage Clamp |
| Features | Interlocking (Side) |
| Color | Green |
| Operating Temperature | -40°C ~ 105°C |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Contact Material – Plating | Brass – Tin Plated |
| Clamp Material – Plating | Brass – Nickel Plated |
| Screw Material – Plating | Steel – Zinc Plated |
| Torque – Screw | 0.4 Nm (3.5 Lb-In) |
| Screw Thread | M2.5 |
| Base Product Number | EB21A |
