Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | YAGEO |
| Series | YC104 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Circuit Type | Isolated |
| Resistance (Ohms) | 0.0 |
| Tolerance | Jumper |
| Number of Resistors | 4 |
| Resistor Matching Ratio | – |
| Resistor-Ratio-Drift | – |
| Number of Pins | 8 |
| Power Per Element | 31mW |
| Temperature Coefficient | – |
| Operating Temperature | -55°C ~ 125°C |
| Grade | Automotive |
| Qualification | AEC-Q200 |
| Applications | DDRAM, SDRAM |
| Mounting Type | Surface Mount |
| Package / Case | 0502 (1406 Metric) Convex, Long Side Terminals |
| Supplier Device Package | – |
| Size / Dimension | 0.055″ L x 0.024″ W (1.40mm x 0.60mm) |
| Height – Seated (Max) | 0.018″ (0.45mm) |
| Base Product Number | YC104-JR |
