Açıklama

ÖZELLİK	AÇIKLAMA
Manufacturer	YAGEO
Series	TC164
Packaging	Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Part Status	Active
Circuit Type	Isolated
Resistance (Ohms)	100
Tolerance	±1%
Number of Resistors	4
Resistor Matching Ratio	–
Resistor-Ratio-Drift	–
Number of Pins	8
Power Per Element	62.5mW
Temperature Coefficient	±200ppm/°C
Operating Temperature	-55°C ~ 155°C
Grade	Automotive
Qualification	AEC-Q200
Applications	DDRAM, SDRAM
Mounting Type	Surface Mount
Package / Case	1206 (3216 Metric), Concave, Long Side Terminals
Supplier Device Package	–
Size / Dimension	0.126″ L x 0.063″ W (3.20mm x 1.60mm)
Height – Seated (Max)	0.028″ (0.70mm)
Base Product Number	TC164-FR
