| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | WINSYSTEMS, INC |
| Series | – |
| Packaging | Box |
| Part Status | Active |
| Core Processor | ARM® Cortex®-A53, ARM® Cortex®-M4, i.MX8M Quad |
| Speed | 1.3GHz |
| Number of Cores | 4 |
| Power (Watts) | – |
| Cooling Type | – |
| Size / Dimension | 3.930″ x 2.830″ (99.82mm x 71.88mm) |
| Form Factor | Pico-ITX |
| Expansion Site/Bus | mPCIe |
| RAM Capacity/Installed | 4GB/0GB |
| Storage Interface | eMMC, MicroSD |
| Video Outputs | HDMI, LVDS |
| Ethernet | GbE (2) |
| USB | USB 2.0 (3), USB 3.1 (1) |
| RS-232 (422, 485) | 2 |
| Digital I/O Lines | – |
| Analog Input:Output | – |
| Watchdog Timer | No |
| Contents | SD Card |
| Operating Temperature | -40°C ~ 85°C |
