Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | WIMA |
| Series | – |
| Packaging | Bulk |
| Part Status | Obsolete |
| Capacitance | 1 µF |
| Tolerance | ±10% |
| Voltage Rating – AC | – |
| Voltage Rating – DC | 50V |
| Dielectric Material | Polyester, Polyethylene Terephthalate (PET), Metallized |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.181″ L x 0.217″ W (4.60mm x 5.50mm) |
| Height – Seated (Max) | 0.394″ (10.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.098″ (2.50mm) |
| Applications | General Purpose |
| Ratings | – |
| Features | – |
