Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | WIMA |
| Series | – |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 0.047 µF |
| Tolerance | ±10% |
| Voltage Rating – AC | 700V |
| Voltage Rating – DC | 2000V (2kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 110°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.043″ L x 0.413″ W (26.50mm x 10.50mm) |
| Height – Seated (Max) | 0.748″ (19.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.886″ (22.50mm) |
| Applications | High Pulse, DV/DT |
| Ratings | – |
| Features | – |
