Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | WIMA |
| Series | – |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 33 pF |
| Tolerance | ±10% |
| Voltage Rating – AC | 250V |
| Voltage Rating – DC | 1000V (1kV) |
| Dielectric Material | Polypropylene (PP) |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.283″ L x 0.177″ W (7.20mm x 4.50mm) |
| Height – Seated (Max) | 0.236″ (6.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.197″ (5.00mm) |
| Applications | High Frequency, Switching; High Pulse, DV/DT |
| Ratings | – |
| Features | – |
