Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | WIMA |
| Series | – |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 0.022 µF |
| Tolerance | ±10% |
| Voltage Rating – AC | 700V |
| Voltage Rating – DC | 6000V (6kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.634″ L x 0.669″ W (41.50mm x 17.00mm) |
| Height – Seated (Max) | 1.142″ (29.00mm) |
| Termination | PC Pins |
| Lead Spacing | 1.476″ (37.50mm) |
| Applications | High Frequency, Switching; High Pulse, DV/DT |
| Ratings | – |
| Features | – |
