Açıklama

ÖZELLİK	AÇIKLAMA
Mfr	WIMA
Series	–
Packaging	Bulk
Part Status	Active
Capacitance	400 µF
Tolerance	±10%
Voltage Rating – AC	–
Voltage Rating – DC	400V
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	1 mOhms
Operating Temperature	-55°C ~ 105°C
Mounting Type	Through Hole
Package / Case	Radial – 4 Leads
Size / Dimension	2.244″ L x 1.772″ W (57.00mm x 45.00mm)
Height – Seated (Max)	2.559″ (65.00mm)
Termination	PC Pins
Lead Spacing	2.067″ (52.50mm)
Applications	Automotive; DC Link, DC Filtering
Ratings	AEC-Q200
Features	–
