Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Weipu Connector |
| Series | SP |
| Packaging | Bulk |
| Part Status | Active |
| Connector Type | Receptacle, Male Pins |
| Number of Positions | 2 |
| Mounting Type | Free Hanging (In-Line), Angled |
| Mounting Feature | Rear Side Nut |
| Termination | Solder |
| Fastening Type | Threaded |
| Primary Material | Plastic |
| Shell Material | Polycarbonate (PC), Nylon 6/6 |
| Contact Finish – Mating | Gold |
| Color | Black, Blue |
| Ingress Protection | IP68 |
| Material Flammability Rating | UL94 V-0 |
| Features | – |
| Shielding | Unshielded |
| Current Rating (Amps) | 5A |
| Voltage Rating | 180VAC |
| Cable Opening | 0.157″ ~ 0.256″ (4.00mm ~ 6.50mm) |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Brass |
| Insert Material | Polyphenylene Sulfide (PPS) |
