Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Weidmüller |
| Series | SAI |
| Packaging | Bulk |
| Part Status | Active |
| Connector Type | Plug, Male Pins |
| Number of Positions | 3 |
| Shell Size – Insert | M8-3 |
| Shell Size, MIL | – |
| Mounting Type | Free Hanging (In-Line) |
| Mounting Feature | – |
| Termination | Screw |
| Fastening Type | Threaded |
| Orientation | – |
| Primary Material | Metal |
| Shell Material | Zinc Die Cast |
| Shell Finish | – |
| Contact Finish – Mating | Gold |
| Color | Black, Silver |
| Ingress Protection | IP67 – Dust Tight, Waterproof |
| Material Flammability Rating | – |
| Features | Backshell |
| Shielding | Unshielded |
| Current Rating (Amps) | 4A |
| Voltage Rating | 60V |
| Cable Opening | 0.138″ ~ 0.197″ (3.50mm ~ 5.00mm) |
| Operating Temperature | -40°C ~ 85°C |
| Backshell Material, Plating | Polyamide (PA), Nylon |
| Contact Material | – |
| Contact Finish Thickness – Mating | – |
| Insert Material | – |
| Applications | Industrial Automation |
| Base Product Number | SAIS |
