| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | VPG Foil Resistors |
| Series | VFCD1505 |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Circuit Type | Voltage Divider |
| Resistance (Ohms) | 5k, 10k |
| Tolerance | ±0.01% |
| Number of Resistors | 2 |
| Resistor Matching Ratio | ±0.01% |
| Resistor-Ratio-Drift | ±0.4ppm/°C |
| Number of Pins | 3 |
| Power Per Element | 50mW |
| Temperature Coefficient | ±0.2ppm/°C |
| Operating Temperature | -55°C ~ 125°C |
| Grade | – |
| Qualification | – |
| Applications | Voltage Divider (TCR Matched) |
| Mounting Type | Surface Mount |
| Package / Case | 1505 (3812 Metric) |
| Supplier Device Package | – |
| Size / Dimension | 0.150″ L x 0.050″ W (3.81mm x 1.27mm) |
| Height – Seated (Max) | 0.025″ (0.64mm) |
