| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Vishay Sfernice |
| Series | PRA100 (CNW) |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Circuit Type | Isolated |
| Resistance (Ohms) | 1k |
| Tolerance | ±0.1% |
| Number of Resistors | 4 |
| Resistor Matching Ratio | ±0.01% |
| Resistor-Ratio-Drift | ±2ppm/°C |
| Number of Pins | 8 |
| Power Per Element | 40mW |
| Temperature Coefficient | ±10ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Grade | Automotive |
| Qualification | AEC-Q200 |
| Applications | – |
| Mounting Type | Surface Mount |
| Package / Case | 0603 (1608 Metric), Convex, Long Side Terminals |
| Supplier Device Package | 0603 |
| Size / Dimension | 0.157″ L x 0.060″ W (4.00mm x 1.52mm) |
| Height – Seated (Max) | 0.025″ (0.64mm) |
