Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Vishay Sfernice |
| Series | P11H |
| Packaging | Box |
| Part Status | Active |
| Resistance (Ohms) | 10k |
| Tolerance | ±10% |
| Power (Watts) | 1W |
| Built in Switch | None |
| Number of Turns | 1.0 |
| Features | High Torque |
| Taper | Linear |
| Number of Gangs | 1 |
| Adjustment Type | User Defined |
| Temperature Coefficient | ±150ppm/°C |
| Rotation | 300° |
| Resistive Material | Cermet |
| Termination Style | Solder Lug |
| Actuator Type | Flatted |
| Actuator Length | 0.750″ (19.05mm) |
| Actuator Diameter | 0.250″ (6.35mm) |
| Bushing Thread | 3/8-32 |
| Mounting Type | Panel Mount |
| Size – Body | Rectangular – 0.516″ x 0.504″ Face (13.10mm x 12.80mm) |
