Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Vishay Sfernice |
| Series | 157 |
| Packaging | Box |
| Part Status | Active |
| Resistance (Ohms) | 10k |
| Tolerance | ±20% |
| Power (Watts) | 1W |
| Built in Switch | None |
| Number of Turns | 1.0 |
| Features | – |
| Taper | Linear |
| Number of Gangs | 1 |
| Adjustment Type | User Defined |
| Temperature Coefficient | ±600ppm/°C |
| Rotation | 360° |
| Resistive Material | Conductive Plastic |
| Termination Style | Solder Turret |
| Actuator Type | Round |
| Actuator Length | 0.500″ (12.70mm) |
| Actuator Diameter | 0.125″ (3.18mm) |
| Bushing Thread | 3/8-32 |
| Mounting Type | Servo Mount |
| Size – Body | Round – 0.874″ Dia (22.20mm) |
