Açıklama

ÖZELLİK	AÇIKLAMA
Manufacturer	Vishay
Series	MPM
Packaging	Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Part Status	Active
Circuit Type	Voltage Divider
Resistance (Ohms)	10k, 10k
Tolerance	±0.1%
Number of Resistors	2
Resistor Matching Ratio	±0.05%
Resistor-Ratio-Drift	±2ppm/°C
Number of Pins	3
Power Per Element	100mW
Temperature Coefficient	±25ppm/°C
Operating Temperature	-55°C ~ 125°C
Applications	Voltage Divider (TCR Matched)
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23-3
Size / Dimension	0.113″ L x 0.051″ W (2.86mm x 1.30mm)
Height – Seated (Max)	0.044″ (1.12mm)
