Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | MKP1848C DC-Link |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 50 µF |
| Tolerance | ±5% |
| Voltage Rating – AC | – |
| Voltage Rating – DC | 600V |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 3 mOhms |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.654″ L x 1.181″ W (42.00mm x 30.00mm) |
| Height – Seated (Max) | 2.244″ (57.00mm) |
| Termination | PC Pins |
| Lead Spacing | 1.476″ (37.50mm) |
| Applications | DC Link, DC Filtering |
| Ratings | – |
| Features | Low ESR; Low ESL; Long Life |
