Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | MKP1839 |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 1 µF |
| Tolerance | ±1% |
| Voltage Rating – AC | 100V |
| Voltage Rating – DC | 160V |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Axial |
| Size / Dimension | 0.413″ Dia x 1.043″ L (10.50mm x 26.50mm) |
| Height – Seated (Max) | – |
| Termination | PC Pins |
| Lead Spacing | – |
| Applications | DC Link, DC Filtering; High Pulse, DV/DT |
| Ratings | – |
| Features | – |
