Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | 150 CRZ |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage – Rated | 50 V |
| ESR (Equivalent Series Resistance) | – |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ High Frequency | 690 mA @ 100 kHz |
| Impedance | 130 mOhms |
| Lead Spacing | – |
| Size / Dimension | 0.492″ Dia (12.50mm) |
| Height – Seated (Max) | 0.551″ (14.00mm) |
| Surface Mount Land Size | 0.492″ L x 0.492″ W (12.50mm x 12.50mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can – SMD |
