Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | 146 CTI |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Capacitance | 220 µF |
| Tolerance | ±20% |
| Voltage – Rated | 50 V |
| ESR (Equivalent Series Resistance) | – |
| Lifetime @ Temp. | 3000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 540 mA @ 100 Hz |
| Ripple Current @ High Frequency | 900 mA @ 100 kHz |
| Impedance | 120 mOhms |
| Lead Spacing | – |
| Size / Dimension | 0.492″ Dia (12.50mm) |
| Height – Seated (Max) | 0.551″ (14.00mm) |
| Surface Mount Land Size | 0.492″ L x 0.492″ W (12.50mm x 12.50mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can – SMD |
