Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | 021 ASM |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage – Rated | 40 V |
| ESR (Equivalent Series Resistance) | 530mOhm |
| Lifetime @ Temp. | 2500 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | – |
| Applications | General Purpose |
| Ripple Current @ High Frequency | 559 mA @ 10 kHz |
| Impedance | 210 mOhms |
| Lead Spacing | – |
| Size / Dimension | 0.394″ Dia x 0.984″ L (10.00mm x 25.00mm) |
| Height – Seated (Max) | – |
| Surface Mount Land Size | – |
| Mounting Type | Through Hole |
| Package / Case | Axial, Can |
