Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | KP 1830 |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 10000 pF |
| Tolerance | ±1% |
| Voltage Rating – AC | 40V |
| Voltage Rating – DC | 63V |
| Dielectric Material | Polypropylene (PP) |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.283″ L x 0.217″ W (7.20mm x 5.50mm) |
| Height – Seated (Max) | 0.276″ (7.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.197″ (5.00mm) |
| Applications | High Frequency, Switching; High Pulse, DV/DT |
| Ratings | – |
| Features | – |
