| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | Mono-Kap™ K |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 0.1 µF |
| Tolerance | ±10% |
| Voltage – Rated | 50V |
| Temperature Coefficient | X7R |
| Operating Temperature | -55°C ~ 125°C |
| Features | – |
| Ratings | – |
| Applications | General Purpose |
| Failure Rate | – |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.157″ L x 0.102″ W (4.00mm x 2.60mm) |
| Height – Seated (Max) | 0.260″ (6.60mm) |
| Thickness (Max) | – |
| Lead Spacing | 0.197″ (5.00mm) |
| Lead Style | Formed Leads |
