Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Vishay Beyschlag/Draloric/BC Components |
| Series | MKP338 6 |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 10000 pF |
| Tolerance | ±20% |
| Voltage Rating – AC | 300V |
| Voltage Rating – DC | 1000V (1kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.689″ L x 0.197″ W (17.50mm x 5.00mm) |
| Height – Seated (Max) | 0.433″ (11.00mm) |
| Termination | PC Pins |
| Lead Spacing | 0.591″ (15.00mm) |
| Applications | Automotive; EMI, RFI Suppression |
| Ratings | AEC-Q200, Y2 |
| Features | – |
