Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | VersaLogic Corporation |
| Series | Blackbird |
| Packaging | Box |
| Part Status | Active |
| Core Processor | Intel Core i7-6822EQ |
| Speed | 2.0GHz, 2.8GHz |
| Number of Cores | 4 |
| Power (Watts) | 21.6W |
| Cooling Type | Heat Plate |
| Size / Dimension | 4.920″ x 3.740″ (124.96mm x 94.99mm) |
| Form Factor | COM Basic |
| Expansion Site/Bus | mPCIe, SATA, PCIe, SPI/SPX, i2C |
| RAM Capacity/Installed | 16GB/16GB |
| Storage Interface | SATA 3.0 (2), mSATA |
| Video Outputs | DP (2), LVDS |
| Ethernet | 10/100/1000 Mbps (2) |
| USB | USB 2.0 (4), USB 3.0 (2) |
| RS-232 (422, 485) | 4 |
| Digital I/O Lines | 24 |
| Analog Input:Output | 8:4 |
| Watchdog Timer | Yes |
| Contents | Keyboard, Mouse |
| Operating Temperature | -20°C ~ 70°C |
| Base Product Number | 1241 |
