| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | VersaLogic Corporation |
| Series | Osprey |
| Packaging | Box |
| Part Status | Obsolete |
| Core Processor | Intel Atom E3845 |
| Speed | 1.91GHz |
| Number of Cores | 4 |
| Power (Watts) | 7.3W |
| Cooling Type | Heat Plate |
| Size / Dimension | 2.170″ x 3.740″ (55.00mm x 95.00mm) |
| Form Factor | COM Mini |
| Expansion Site/Bus | mPCIe, SATA, microSD, I2C |
| RAM Capacity/Installed | 4GB/4GB |
| Storage Interface | SATA 2.0, eMMC, microSD, mSATA |
| Video Outputs | DP, LVDS |
| Ethernet | 10/100/1000 Mbps (2) |
| USB | USB 2.0 (4), USB 3.0 (1) |
| RS-232 (422, 485) | 2 |
| Digital I/O Lines | 8 |
| Analog Input:Output | – |
| Watchdog Timer | Yes |
| Contents | Keyboard, Mouse |
| Operating Temperature | -40°C ~ 85°C |
| Base Product Number | 1241 |
