Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | u-blox |
| Series | ZED-F9T |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Frequency | 1.166GHz ~ 1.212GHz, 1.192GHz ~ 1.231GHz, 1.223GHz ~ 1.286GHz, 1.559GHz ~ 1.563GHz, 1.573GHz ~ 1.578GHz |
| Sensitivity | -128dBm |
| Data Rate (Max) | 921.6kBaud |
| Modulation or Protocol | BeiDou, Galileo, GLONASS, GNSS, GPS, QZSS |
| Applications | General Purpose |
| Current – Receiving | – |
| Data Interface | I2C, PIO, SPI, UART, USB |
| Memory Size | – |
| Antenna Connector | Not Included |
| Features | – |
| Voltage – Supply | 2.7V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | – |
| Qualification | – |
| Mounting Type | Surface Mount |
| Package / Case | 54-SMD Module |
| Supplier Device Package | 54-LGA (22×17) |
