Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | TXC CORPORATION |
| Series | AM |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | MHz Crystal |
| Frequency | 16 MHz |
| Frequency Stability | ±150ppm |
| Frequency Tolerance | ±30ppm |
| Load Capacitance | 12pF |
| ESR (Equivalent Series Resistance) | 100 Ohms |
| Operating Mode | Fundamental |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | AEC-Q200 |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Supplier Device Package | 4-SMD (3.2×2.5) |
| Size / Dimension | 0.126″ L x 0.098″ W (3.20mm x 2.50mm) |
| Height – Seated (Max) | 0.031″ (0.80mm) |
