Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Texas Instruments |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | Standard (General Purpose) |
| Number of Elements | 1 |
| Output Type | Push-Pull |
| Voltage – Supply, Single/Dual (±) | 3.3V ~ 40V, ±1.65V ~ 20V |
| Voltage – Input Offset (Max) | 4.5mV @ 40V |
| Current – Input Bias (Max) | 500pA |
| Current – Output (Typ) | 85mA @ 40V |
| Current – Quiescent (Max) | 150µA |
| CMRR, PSRR (Typ) | 60dB CMRR, 70dB PSRR |
| Propagation Delay (Max) | 250ns (Typ) |
| Hysteresis | 15mV |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Package / Case | SOT-23-6 |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23-6 |
| Base Product Number | TLV1805 |
