Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Texas Instruments |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | Standard (General Purpose) |
| Number of Elements | 2 |
| Output Type | Open-Collector |
| Voltage – Supply, Single/Dual (±) | 2.2V ~ 36V, ±1.1V ~ 18V |
| Voltage – Input Offset (Max) | 2.5mV |
| Current – Input Bias (Max) | 0.015µA |
| Current – Output (Typ) | 20mA |
| Current – Quiescent (Max) | 75µA |
| CMRR, PSRR (Typ) | – |
| Propagation Delay (Max) | 560ns |
| Hysteresis | – |
| Operating Temperature | -40°C ~ 125°C |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Package / Case | 8-TSSOP, 8-MSOP (0.118″, 3.00mm Width) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-VSSOP |
| Base Product Number | TLV1702 |
