Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | F7 |
| Packaging | Bulk |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 70 A |
| Switching Voltage | 12VDC – Nom |
| Must Operate Voltage | 7.2 VDC |
| Must Release Voltage | 1.6 VDC |
| Operate Time | 7 ms |
| Release Time | 2 ms |
| Features | – |
| Mounting Type | Chassis Mount |
| Termination Style | Plug In, Quick Connect – Multiple Sizes |
| Operating Temperature | -40°C ~ 125°C |
| Contact Material | Silver Alloy |
| Coil Power | 1.6W |
| Coil Resistance | 90 Ohms |
| Base Product Number | V23134 |
