Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Series | R10 |
| Packaging | Bulk |
| Part Status | Not For New Designs |
| Mounting Type | Socketable |
| Coil Voltage | 24VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 3 A |
| Switching Voltage | 120VAC – Nom |
| Load – Max Switching | – |
| Coil Current | 20 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | Plug In |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | 20.5 VDC |
| Must Release Voltage | 0.12 VDC |
| Operating Temperature | -55°C ~ 75°C |
| Contact Material | Silver (Ag) |
| Approval Agency | CSA, UR |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 5 kOhms |
| Base Product Number | R10-E1Y2 |
