Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | HF3, AXICOM |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Current | 46.7 mA |
| Coil Voltage | 3VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 250VAC, 220VDC – Max |
| Must Operate Voltage | 2.25 VDC |
| Must Release Voltage | 0.3 VDC |
| Operate Time | 5 ms |
| Release Time | 4 ms |
| Features | – |
| Mounting Type | Surface Mount |
| Termination Style | Gull Wing |
| Operating Temperature | -55°C ~ 85°C |
| Contact Material | Silver (Ag), Gold (Au) |
| Coil Power | 140mW |
| Coil Resistance | 64 Ohms |
| Base Product Number | 1462051 |
