Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | TE Connectivity Passive Product |
| Series | ROX, Neohm |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Active |
| Resistance | 220 Ohms |
| Tolerance | ±5% |
| Power (Watts) | 0.5W, 1/2W |
| Composition | Metal Oxide Film |
| Features | Flame Proof, Pulse Withstanding, Safety |
| Temperature Coefficient | ±350ppm/°C |
| Operating Temperature | -55°C ~ 130°C |
| Package / Case | Axial |
| Supplier Device Package | Axial |
| Size / Dimension | 0.098″ Dia x 0.295″ L (2.50mm x 7.50mm) |
| Height – Seated (Max) | – |
| Number of Terminations | 2 |
| Failure Rate | – |
| Base Product Number | ROX05 |
