Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | TE Connectivity Passive Product |
| Series | EP, Neohm |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Active |
| Resistance | 100 Ohms |
| Tolerance | ±5% |
| Power (Watts) | 1W |
| Composition | Wirewound |
| Features | Flame Retardant Coating, Pulse Withstanding, Safety |
| Temperature Coefficient | ±300ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | Axial |
| Supplier Device Package | Axial |
| Size / Dimension | 0.138″ Dia x 0.394″ L (3.50mm x 10.00mm) |
| Height – Seated (Max) | – |
| Number of Terminations | 2 |
| Failure Rate | – |
