Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | TE Connectivity ALCOSWITCH Switches |
| Series | Gemini A |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Panel Mount |
| Circuit | DPDT |
| Switch Function | On-On |
| Current Rating (Amps) | 5A (AC/DC) |
| Voltage Rating – AC | 120 V |
| Voltage Rating – DC | 28 V |
| Actuator Type | Standard Round |
| Actuator Length | 17.45mm |
| Illumination | Non-Illuminated |
| Illumination Type, Color | – |
| Illumination Voltage (Nominal) | – |
| Termination Style | Solder Lug |
| Panel Cutout Dimensions | Circular – 12.00mm Dia |
| Bushing Thread | 15/32-32 |
| Ingress Protection | – |
| Features | Epoxy Sealed Terminals |
| Operating Temperature | -30°C ~ 85°C |
| Actuator Material | Brass, Nickel Plated |
| Electrical Life | 6,000 Cycles |
| Base Product Number | 1825138 |
