Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | TDK Corporation |
| Series | SDR |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Last Time Buy |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | 0 ~ 5V |
| Frequency | 2.67kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 88dB @ 3V, 10cm |
| Current – Supply | 85mA |
| Port Location | Side |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.335″ L x 0.335″ W (8.50mm x 8.50mm) |
| Height – Seated (Max) | 0.165″ (4.20mm) |
