| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | TDK Corporation |
| Series | PS |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | 0 ~ 30V |
| Frequency | 4kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 60dB @ 3V, 10cm |
| Current – Supply | – |
| Port Location | Top |
| Operating Temperature | -10°C ~ 70°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.480″ Dia (12.20mm) |
| Height – Seated (Max) | 0.181″ (4.60mm) |
